Descrição do produto
|Type||vertical single cylinder, 4-stroke, forced air-cooling,SV, horizontal shaft||25° Inclined Single Cylinder, 4 stroke, OHV, Horizontal Shaft, Forced Air-Cooling|
|Cylinder Dia. × Stroke||54mm×38mm||68mm × 45mm||68mm × 54mm||70mm ×54mm||77mm ×58mm||88mm ×64mm||90mm ×66mm|
|Max. Power Output||2.8hp / 2.2kw / 3600rpm||5.5hp / 4.1kw / 3600rpm||6.5hp / 4.8kw / 3600rpm||7.0hp / 5.1kw / 3600rpm||9.0hp / 6.75kw / 3600rpm||13hp / 9.6kw / 3600rpm||15hp / 11.2kw / 3600rpm|
|Rated Power Output||1.9hp / 1.4kw / 3600rpm||4.85hp / 3.61kw / 3600rpm||5.8hp / 4.3kw / 3600rpm||6.0hp / 4.4kw / 3600rpm||8.2hp / 6.12kw / 3600rpm||11.7hp / 8.6kw / 3000rpm||14hp / 10.5kw / 3000rpm|
|Max. Torque||3.5N.M. / 2500rpm||10.8N.M / 2500rpm||13.2N.M / 2500rpm||14N.M / 2500rpm||19.1N.M / 2500rpm||26.5N.M / 2500rpm||28N.M / 2500rpm|
|Ignition Mode||Non-Contact Transistor Magneto||Non-Contact Transistor Magneto|
|Starting Mode Options||Recoil / Electric|
|Engine Oil Capacity||0.4L||0.6L||0.6L||0.6L||1.1L||1.1L||1.1L|
|Recommended Fuel||unleaded gasoline|
|Recommended Engine Oil||SAE 10W-30|
|Fuel Consumption Rate||260g / hp.h||360g / kw.h||360g / kw.h||360g / kw.h||325g / kw.h||325g / kw.h||374g / kw.h|
|Carburetor Type||Float Carburetor|
|Fuel Suppling Mode||gravity feed|
|Power Output Form||crank shaft 1:1|
|Output End of Crank Shaft||Metric Thread / British Thread / Keyslot|
|Crank Shaft Rotation Direction||Clockwise (view from flywheel)|
|Air Filter Type||Semi-Dry / Oil Bath / Semi-Dry+Oil Bath|
|N.W./G.W.||10kgs / 11kgs||15kgs / 16kgs||15kgs / 16kgs||15.5kgs / 16.5kgs||25kgs / 26kgs||31kgs / 33kgs||31.5kgs / 33.5kgs|
